ADV
|
K29/180 |
| Single Cylinder，four stroke，forced air cooling，horizontal cyclinder、lower mounted |
| Power System | |
| Maxium Speed | 122 Km/h |
| Cylinder Bore | 63mm |
| Piston Stroke | 57.9mm |
| Compression Ratio | 9.5:1 |
| Ignition Type | ECU |
| MAX Power | 10.4kw (7500r/min) |
| MAX torque | 14.7N.M (6000R/min) |
| Tank Capacity | 12L |
| Oil consumption |
3.8L/100km（carburetor） 3.0L/100km (EFI) |
| DIMEMSION | |
| L*W*H | 1960×730×1170mm |
| Wheelbase | 1330mm |
| Min.Ground Clearance | 170mm |
| Seat Height | 800mm |
| Net Weight | 130kg |
| Framework | |
| Front Shock Absorber | straight cylinder hydraulic L:465 |
| Rear Shock Absorber | double shock absorber bolded spring with air bottle L:395 |
| Front/Rear Tire Spec | Vacuum tire front:110/80-14 rear:130/70-13 |
| Braking Mode | front & rear discCBS |
| rim | Alu. Alloy front:14×MT2.50 rear:13×MT3.50 |
| Frame material | High quality carbon steel |
| Battery | 12V-8.6A |
water cooling150CC configuration are available
EFI Carburetor configuration optional
